Description
Specification
Metal fire protection duct for encapsulation of fire loads with active fire retardation | No propagation of fire in the duct; actively inhibits fire
Low space requirements as virtually the entire duct cross-section is usable
Fast, simple installation; easily mountable, self-closing components
Dust-free installation
Simple fastening, even directly on ceilings or walls
Easily accessible, therefore maintenance-friendly; easy and simple to add to installation at a later stage
Cable versions available with metal or plastic cable fittings in accordance with EN 60 423
Dimensionally stable
Special designs also deliverable via special order: Two-sided, three-sided, four-sided, round duct, stainless steel duct, surfaces in RAL colours
Interior coating begins to react at +200°C
Low tare weight | No propagation of fire in the duct; actively inhibits fire | Low space requirements as virtually the entire duct cross-section is usable | Fast, simple installation; easily mountable, self-closing components | Dust-free installation | Simple fastening, even directly on ceilings or walls | Easily accessible, therefore maintenance-friendly; easy and simple to add to installation at a later stage | Cable versions available with metal or plastic cable fittings in accordance with EN 60 423 | Dimensionally stable | Special designs also deliverable via special order: Two-sided, three-sided, four-sided, round duct, stainless steel duct, surfaces in RAL colours | Interior coating begins to react at +200°C | Low tare weight | Notice | Where cables and pipes are placed directly on the element, the permissible total weight resulting from cable and pipe weight ≤ 34 kg/m.
Store dry and frost-free | Where cables and pipes are placed directly on the element, the permissible total weight resulting from cable and pipe weight ≤ 34 kg/m. | Store dry and frost-free | General technical approval Z-19.30-2214
Fire resistance duration I 30 to I 120 | General technical approval Z-19.30-2214 | Fire resistance duration I 30 to I 120
Application
Application area | For use in system E4 | Fire protection duct I 30/I 60/I 90/I 120 for encapsulation of combustibles | Escape and rescue routes, as well as in essential corridors and stairwells
Suitable for cables, flammable pipes and non-flammable pipes with flammable synthetic rubber insulation
The I-duct can be routed through fire-resistant solid and lightweight partition walls
Duct itself can act as a cable conduit | Escape and rescue routes, as well as in essential corridors and stairwells | Suitable for cables, flammable pipes and non-flammable pipes with flammable synthetic rubber insulation | The I-duct can be routed through fire-resistant solid and lightweight partition walls | Duct itself can act as a cable conduit | Instructions | When installing the fire protection duct, make sure to comply with the installation instructions and test certificate no. P-MPA-E-09-011.
Tehnical Information
Width x height: 50 x 30 mm | Length: 1000 mm | Fire resistance rating: I120 | Surface: Zinc plated | Colour: Silver grey | Material: Steel / steel
