Description

Specification
For WIT injection systems in concrete and masonry | The anchor rod is covered by the following approvals: | Injection system ALLROUNDER WIT-VM 250, Option 1: ETA-12/0164

Injection system WIT-Nordic, Option 1: ETA-12/0164

Injection system CONCRETE-MULTI WIT-UH 300, Option 1: ETA-17/0127

Injection system PURE-EPOXY WIT-PE 1000, Option 1: ETA-19/0542

Injection system WIT-PE 500, Option 1: ETA-09/0040

Injection system BASIC WIT-PM 200, Option 7: ETA-12/0569

Injection system W-VI (injectable mortar WIT-Express), option 7: ETA-05/0034

Injection system BASIC WIT-PM 200, masonry: ETA-13/0037

Injection system ALLROUNDER WIT-VM 250, masonry: ETA-16/0757, ETA-20/0854 | Injection system ALLROUNDER WIT-VM 250, Option 1: ETA-12/0164 | Injection system WIT-Nordic, Option 1: ETA-12/0164 | Injection system CONCRETE-MULTI WIT-UH 300, Option 1: ETA-17/0127 | Injection system PURE-EPOXY WIT-PE 1000, Option 1: ETA-19/0542 | Injection system WIT-PE 500, Option 1: ETA-09/0040 | Injection system BASIC WIT-PM 200, Option 7: ETA-12/0569 | Injection system W-VI (injectable mortar WIT-Express), option 7: ETA-05/0034 | Injection system BASIC WIT-PM 200, masonry: ETA-13/0037 | Injection system ALLROUNDER WIT-VM 250, masonry: ETA-16/0757, ETA-20/0854
Application
Application area | Anchor rod can be used for the following injection systems: | Injection system ALLROUNDER WIT-VM 250, Option 1 – cracked and uncracked concrete

Injection system WIT-Nordic, Option 1 – cracked and uncracked concrete

Injection system CONCRETE-MULTI WIT-UH 300 – cracked and uncracked concrete

Injection system PURE-EPOXY WIT-PE 1000 – cracked and uncracked concrete

Injection system WIT-PE 500, Option 1 – cracked and uncracked concrete

Injection system BASIC WIT-PM 200, Option 7 – uncracked concrete

Injection system W-VI (injectable mortar WIT-Express), Option 7 – uncracked concrete

Injection system BASIC WIT-PM 200, masonry – solid and perforated bricks, aerated concrete

Injection system ALLROUNDER WIT-VM 250, masonry – solid and perforated brick, aerated concrete | Injection system ALLROUNDER WIT-VM 250, Option 1 – cracked and uncracked concrete | Injection system WIT-Nordic, Option 1 – cracked and uncracked concrete | Injection system CONCRETE-MULTI WIT-UH 300 – cracked and uncracked concrete | Injection system PURE-EPOXY WIT-PE 1000 – cracked and uncracked concrete | Injection system WIT-PE 500, Option 1 – cracked and uncracked concrete | Injection system BASIC WIT-PM 200, Option 7 – uncracked concrete | Injection system W-VI (injectable mortar WIT-Express), Option 7 – uncracked concrete | Injection system BASIC WIT-PM 200, masonry – solid and perforated bricks, aerated concrete | Injection system ALLROUNDER WIT-VM 250, masonry – solid and perforated brick, aerated concrete | W-VI-A/S (zinc-plated steel) can be used in dry indoor areas.
Tehnical Information
Type description: W-VI-A/S | Property class: 5.8 | Metric anchor diameter: M12 | Anchor length (l): 175 mm | Nominal drill-bit diameter injection system (d 0): 14 mm | Approval: ETA-09/0040, ETA-12/0164, ETA-05/0034, ETA-12/0569, ETA-13/0037, ETA-16/0757, ETA-17/0127, ETA-19/0542, ETA-20/0854, ETA-20/1038 | Suitable for perforated sleeve: SH 20 x 85, SH 20 x 130 | Material: Steel
